From the heart of Hamilton’s industrial landscape, Latham Steel has built a reputation as a trusted manufacturer and supplier, known for precision and reliability. We take particular pride in our expertise with materials like Carbon Steel A334 GR 9 Tubing, a specification vital for demanding environments. Our team understands the critical nature of these components, ensuring every length of tubing we provide meets the exacting standards required for safety and performance, supporting industries both locally in New Zealand and across the globe with unwavering quality.
The strength of A334 GR 9 tubing lies in its carefully balanced composition, primarily carbon and manganese, which gives it exceptional mechanical properties. This specific grade is engineered to perform reliably in low-temperature service, maintaining excellent toughness where other materials might become brittle. It offers a superb combination of tensile strength and yield strength, allowing it to withstand significant pressure and stress. This reliable blend of chemistry and physical characteristics makes it a go-to choice for critical applications where failure is not an option.
| Element | A/SA 334 Gr A9 |
| C | 0.30 max |
| Mn | 0.40-1.06 |
| P | 0.025 max |
| S | 0.025 max |
| Element | A/SA 334 |
| Tensile Strength, (MPa) | 380 min |
| Yield Strength, (MPa) | 205 min |
| Elongation min. % | 35 |
| Hardness, HB | 163 max |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a leading manufacturer and supplier of Carbon Steel A334 GR 8 Tubing in Hamilton, New Zealand. We provide top-quality steel materials and a wide range of products, including Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel. Our extensive inventory consists of Tubes, Pipes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. With a strong commitment to fast delivery and exceptional customer service, we ensure that all our products are made from the finest raw materials, guaranteeing superior strength, durability, and performance for demanding industrial applications. Get in touch with us today for your Carbon Steel A334 GR 8 Tubing requirements!
| Outside | Nominal | Wall | Inside | Weight |
| Diameter | Pipe Diameter | Thickness | Diameter | Lbs |
| Inches | Inches | Inches | Inches | Per Foot |
| 1.660 | 1-1/4 | .140 | 1.380 | 2.273 |
| 1.315 | 1 | .133 | 1.049 | 1.679 |
| 1.900 | 1-1/2 | .145 | 1.610 | 2.718 |
| 2.875 | 2-1/2 | .203 | 2.469 | 5.793 |
| 2.375 | 2 | .154 | 2.067 | 3.653 |
| 6.625 | 6 | .28 | 6.056 | 18.97 |
| 3.50 | 3 | .216 | 3.068 | 7.576 |
| 4.50 | 4 | .237 | 4.026 | 10.79 |
| 4 | 3-1/2 | .226 | 3.548 | 9.109 |
| 5.563 | 5 | .258 | 5.047 | 14.62 |
| 8.625 | 8 | .322 | 7.981 | 28.55 |
This high-performance tubing is essential for systems that operate under pressure in cold climates. You’ll typically find it in heat exchangers, condensers, and intricate piping systems within power generation facilities, chemical plants, and refrigeration units. Its ability to remain ductile and crack-resistant at sub-zero temperatures makes it invaluable for safely transporting liquids and gases. Essentially, A334 GR 9 is the silent, reliable workhorse behind the scenes in many industrial processes, ensuring operational integrity where temperature and pressure create a challenging environment.
Latham Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Hamilton, New Zealand.
