From the heart of Hamilton, New Zealand, Latham Steel has built a reputation for reliable expertise and quality materials. We are proud to be your trusted local supplier for high-performance components like Carbon Steel A334 GR 1 Tubing. This specific grade is engineered to excel in demanding low-temperature environments, making it a critical material for industries where failure is not an option. Our team understands these high-stakes applications and is dedicated to providing not just the product, but the knowledgeable support that comes with it.
The composition of Carbon Steel A334 GR 1 is carefully balanced to achieve its notable low-temperature toughness. Primarily a carbon-manganese steel, it includes controlled levels of silicon and other elements to enhance its strength and durability. This combination results in excellent mechanical properties, including a specified minimum yield strength that ensures structural integrity. Crucially, it is designed to remain ductile and resist brittle fracture even when subjected to the extreme cold that would cause other materials to become brittle and fail.
| Element | A/SA 334 Gr A1 |
| C | 0.30 max |
| Mn | 0.40-1.06 |
| P | 0.025 max |
| S | 0.025 max |
| Element | A/SA 334 |
| Tensile Strength, (MPa) | 380 min |
| Yield Strength, (MPa) | 205 min |
| Elongation min. % | 35 |
| Hardness, HB | 163 max |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a trusted manufacturer and supplier of high-quality Carbon Steel A423 GR 1 Tubing in Hamilton, New Zealand. We provide premium steel materials and a comprehensive range of products, including Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel. Our extensive inventory includes Tubes, Pipes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. With a commitment to fast delivery and exceptional customer service, we source top-grade raw materials to ensure outstanding strength and durability for demanding industrial applications. Contact us today for all your Carbon Steel A423 GR 1 Tubing requirements!
| Outside | Nominal | Wall | Inside | Weight |
| Diameter | Pipe Diameter | Thickness | Diameter | Lbs |
| Inches | Inches | Inches | Inches | Per Foot |
| 1.660 | 1-1/4 | .140 | 1.380 | 2.273 |
| 1.315 | 1 | .133 | 1.049 | 1.679 |
| 1.900 | 1-1/2 | .145 | 1.610 | 2.718 |
| 2.875 | 2-1/2 | .203 | 2.469 | 5.793 |
| 2.375 | 2 | .154 | 2.067 | 3.653 |
| 6.625 | 6 | .28 | 6.056 | 18.97 |
| 3.50 | 3 | .216 | 3.068 | 7.576 |
| 4.50 | 4 | .237 | 4.026 | 10.79 |
| 4 | 3-1/2 | .226 | 3.548 | 9.109 |
| 5.563 | 5 | .258 | 5.047 | 14.62 |
| 8.625 | 8 | .322 | 7.981 | 28.55 |
This tubing is indispensable in applications where equipment must operate reliably in frigid conditions. You will commonly find it in the heat exchangers, condensers, and pipeline systems of liquefied gas plants, cryogenic storage facilities, and refrigeration units. Its ability to maintain strength and prevent cracking makes it a go-to choice for the oil and gas industry, particularly in processing plants handling cold fluids. Essentially, anywhere operations dip to very low temperatures, A334 GR 1 provides the dependable, life-cycle performance that engineers and project managers count on.
Latham Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Hamilton, New Zealand.
