For over four decades, Latham Steel has been a trusted partner in Hamilton, New Zealand, providing industry with high-quality steel tubing solutions. Our dedication to precision manufacturing ensures a reliable supply of ASTM A513 tubing, a product we know is critical for your projects. We take pride in supporting the local and national engineering sector with materials that meet rigorous international standards, backed by our team’s deep expertise and a commitment to customer service that has been our hallmark since the beginning.
The makeup of ASTM A513 tubing is primarily carbon steel, chosen for its excellent balance of strength and formability. This gives the tubing impressive mechanical properties, offering good yield and tensile strength while remaining relatively easy to weld, bend, or machine to your specifications. It’s this dependable combination that makes it such a versatile choice for so many applications, providing a solid and cost-effective foundation for building everything from simple frames to complex machinery.
| Grade: | ASME/ASTM SA179, SA192, SA210, SA178, SA214, API 5L |
|---|---|
| Size: | 1/8” NB TO 24” NB Sch 40/80/160/XXS |
| Form | Round, Square, Rectangular, Coil, U Tube, |
| Length | Single Random, Double Random & Required Length |
| End | Plain End, Bevelled End |
| Type | Seamless / ERW / Welded |
| Certification For Carbon | Mill Test Certificate as per EN 10204 / 3.2B |
| General Requirements | ASTM A 530/A 530M |
| Dimensional Tolerances | ANSI B 36.10 |
| OD Range | 1.250″ – 6.000″ (30-150mm) |
| Wall Range | 0.095″ – 1.000″ (.2.5-25mm) |
| Composition, % | ||||
| Element | Grades A, B and D | Grace C | ||
| Heat Analysis | Product Analysis | Heat Analysis | Product Analysis | |
| Carbon, max | 0.26 | 0.30 | 0.23 | 0.27 |
| Manganese, max | … | … | 1.35 | 1.40 |
| Phosphorus, max | 0.035 | 0.045 | 0.035 | 0.045 |
| Sulfur, max | 0.035 | 0.045 | 0.035 | 0.045 |
| Copper, when copper steel is specified, min | 0.20 | 0.18 | 0.20 | 0.18 |
| Yield Strength, min | 170 MPa |
| Ultimate Strength, min | 310 MPa |
| Elongation in 50 mm, min | 35% |
| Hardness (Rockwell B), max | 65 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| 1½ (38.1) and under | 0.050 | 1.39 | |
| Over 1½ to 2½ (38.1 to 63.5),incl | 0.062 | 1.72 | |
| Over 2½ to 4 (63.5 to 101.6), incl | 0.075 | 2.09 | |
| Over 4 to 6 (101.6 to 152.4), incl | 0.087 | 2.42 | |
| Over 6 to 8 (152.4 to 203.2), incl | 0.100 | 2.78 | |
| Over 8 (203) | 0.112 | 3.11 | |
You’ll find our ASTM A513 tubing hard at work in a remarkable range of applications. It’s the backbone for countless industrial handrails, machine frames, and structural supports where strength and reliability are non-negotiable. Beyond the factory, it’s essential in agricultural equipment, automotive parts, and even in creating the furniture and display units we see every day. Essentially, wherever a project calls for a durable, hollow steel section that is easy to fabricate, this tubing proves to be an indispensable and economical solution.
Latham Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Hamilton, New Zealand.
