Latham Steel, based in the industrial heart of Hamilton, New Zealand, is proud to be your trusted partner for robust and reliable piping solutions. We understand the critical demands of challenging environments, which is why we specialize in supplying high-quality Carbon Steel A334 GR 3 Tubing. This specific grade is engineered to perform exceptionally well in low-temperature service, making it a go-to choice for industries where resilience and integrity are non-negotiable, from energy processing to specialized industrial applications.
The composition of this tubing is a careful balance of carbon and manganese, creating a material that is both strong and reliable. Its key characteristic lies in its outstanding mechanical properties, specifically its toughness and ductility at sub-zero temperatures. This means the tubing can withstand significant impact and stress even in extremely cold conditions without becoming brittle, ensuring a consistent and safe performance where other materials might fail.
| Element | A/SA 334 Gr A3 |
| C | 0.30 max |
| Mn | 0.40-1.06 |
| P | 0.025 max |
| S | 0.025 max |
| Element | A/SA 334 |
| Tensile Strength, (MPa) | 380 min |
| Yield Strength, (MPa) | 205 min |
| Elongation min. % | 35 |
| Hardness, HB | 163 max |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a trusted manufacturer and supplier of high-quality Carbon Steel A334 GR 3 Tubing in Hamilton, New Zealand. We offer premium steel materials and a comprehensive range of products, including Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel. Our extensive inventory features Tubes, Pipes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Committed to fast delivery and exceptional customer service, we source top-grade raw materials to ensure superior strength and durability for demanding industrial applications. Contact us today for all your Carbon Steel A334 GR 3 Tubing needs!
| Outside | Nominal | Wall | Inside | Weight |
| Diameter | Pipe Diameter | Thickness | Diameter | Lbs |
| Inches | Inches | Inches | Inches | Per Foot |
| 1.660 | 1-1/4 | .140 | 1.380 | 2.273 |
| 1.315 | 1 | .133 | 1.049 | 1.679 |
| 1.900 | 1-1/2 | .145 | 1.610 | 2.718 |
| 2.875 | 2-1/2 | .203 | 2.469 | 5.793 |
| 2.375 | 2 | .154 | 2.067 | 3.653 |
| 6.625 | 6 | .28 | 6.056 | 18.97 |
| 3.50 | 3 | .216 | 3.068 | 7.576 |
| 4.50 | 4 | .237 | 4.026 | 10.79 |
| 4 | 3-1/2 | .226 | 3.548 | 9.109 |
| 5.563 | 5 | .258 | 5.047 | 14.62 |
| 8.625 | 8 | .322 | 7.981 | 28.55 |
This unique combination of properties makes A334 GR 3 tubing indispensable for systems that operate in cold climates or handle refrigerated substances. You’ll commonly find it in critical applications like heat exchangers and condensers within power generation facilities, as well as throughout gas processing and petrochemical plants. It is also the preferred material for pipelines transporting liquefied gases, ensuring safe and efficient flow from one point to another, even when the mercury plummets.
