For decades, Latham Steel has been a cornerstone of Hamilton’s industrial landscape, building a reputation for precision and reliability. We take pride in our role as a trusted manufacturer and supplier, especially when it comes to high-performance materials like Alloy Steel T91 Tubing. Our commitment extends beyond supply, offering expert guidance to ensure our clients in New Zealand and beyond find the exact solution for their most demanding high-temperature and high-pressure applications, backed by local knowledge and global standards.
Alloy Steel T91 is specifically engineered with a precise balance of chromium, molybdenum, and vanadium, along with nitrogen and niobium. This composition gives it a distinct advantage: remarkable strength and resistance to oxidation at elevated temperatures. Essentially, it maintains its structural integrity under intense heat and pressure where other steels would soften, making it a go-to material for critical, high-stress environments that demand long-term durability and safety.
| ASTM A213 T91 Specification & Standard | ASTM A213 T91, ASME SA213 T91 (with IBR Test Certificate) |
|---|---|
| SA 213 Gr T91 Specification | ASTM A213 & ASTM A209 BS/3059/ 90/ Part II/ 620 & 622 DIN/ 17175/ 13CrMo44 DIN/ 17175/ 10CrMo910 DIN/ 17175/ 15Mo3 |
| T91 Steel Tube Sch. & Swg. | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg., 3.6 mm Thk |
| ASTM A213 T91 Tubing Size | 6.35 mm OD to 101.6 mm OD |
| ASTM A213 T91 Pipe Thickness | 3-12mm |
| ASME SA213 Gr T91 Material Origin | European, Japanese, Korean, US, Russian, New Zealandn (Strictly No Chinese Material) |
| Craft | Cold rolled and Cold drawn |
| ASTM A213 T91 Tube Type | Seamless / ERW / Welded / Fabricated |
| SA213 T91 Steel Tube available in Form of | Round, Square, Rectangular, Hydraulic Etc. |
| ASTM SA213 T91 Tube Tolerance | Cold drawn pipe: +/-0.1mm Cold rolled pipe: +/-0.05mm |
| ASME SA213 Grade T91 Tube Length | Standard Double & In Cut length also. |
| ASME SA213 Gr T91 Tube End | Plain End, Beveled End, Treaded |
| ASTM A213 T91 Additional Testing | NACE MR 0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, H2 SERVICE, IBR, etc. |
| Specialized in |
|
| ASME SA213 Grade T91 Tube Application & uses | Seamless Ferritic ASTM A213 T91 Tubing for High-Temperature Service |
| Grade | C≤ | Mn | P≤ | S≤ | Si≤ | Mo |
|---|---|---|---|---|---|---|
| SA213 T91 Composition |
0.07~0.14 |
0.30~0.60 |
0.02 |
0.02 |
0.20~0.50 |
0.85~1.05 |
| Grade | Tensile Strength, MPa | Yield Strength, MPa | Elongation, % | Hardness, HB |
|---|---|---|---|---|
| ASTM A213 T91 Tubing | 585 min | 415 min | 20 min | 250 max |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Outside Diameter | OD Tolerance | WT Tolerance | Ovality Tolerance | Cut Length Tolerance |
| OD≤ 12, 7 mm | ± 0, 13 mm | ± 15 % | – | + 3, 18 mm, – 0 mm |
| 12, 7 mm < OD ≤ 38, 1 mm | ± 0, 13 mm | ± 10 % | max, 1, 65 mm | + 3, 18 mm, – 0 mm |
| 38, 1 mm < OD ≤ 88, 9 mm | ± 0, 25 mm | ± 10 % | max, 2, 41 mm | + 4, 76 mm, – 0 mm |
Jaxon Steel is a leading manufacturer and distributor of high-quality Alloy Steel T91 Tubing in Hamilton, New Zealand. We provide top-grade steel materials and a diverse range of products, including Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel. Our comprehensive inventory features Tubes, Pipes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Dedicated to on-time delivery and outstanding customer service, we source only the best raw materials to guarantee superior performance in industrial applications with demanding specifications. Reach out to us today for all your Alloy Steel T91 Tubing requirements!
This unique combination of properties makes Alloy Steel T91 tubing indispensable in power generation, particularly within the superheater and reheater sections of advanced boilers. You’ll also find it serving a vital role in high-temperature piping systems for petrochemical plants and in various demanding industrial process equipment. Its ability to withstand extreme conditions reduces maintenance needs and extends the operational life of critical infrastructure, making it a smart, long-term investment for any project where heat and pressure are fundamental challenges.
