Operating from the industrial heart of Hamilton, Latham Steel has built a trusted reputation for supplying high-grade materials to New Zealand’s critical sectors. We take pride in our expertise with Alloy Steel T23 Tubing, a product we source and deliver with a commitment to unwavering quality and reliability. Our team understands the demanding environments our clients operate in, which is why we ensure our T23 tubing meets the most stringent specifications, providing a robust and dependable solution for complex projects across the country.
This particular alloy is recognized for its well-balanced composition, primarily chromium, molybdenum, and tungsten, with a careful addition of vanadium. This blend gives the steel its notable strength and stability when faced with high temperatures. The resulting mechanical properties are impressive, offering excellent creep resistance, which means it can withstand constant stress under extreme heat without deforming. This makes it a wonderfully durable and long-lasting material for demanding thermal applications.
| SA213 T23 Tube Standard | ASTM A213 T23, SA213 T23 (with IBR Test Certificate) |
|---|---|
| SA213 T23 Tube Specifications | ASTM A213 & ASTM A209 (T1 , Ta, T1b) BS/3059/90/PartII/620 & 622 DIN/17175/13CrMo44 DIN/17175/10CrMo910 DIN/17175/15Mo3 |
| SA213 T23 Tube Size | 6.35 mm OD to 101.6 mm OD |
| Sch. & Swg. | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg., 3.6 mm Thk |
| SA213 T23 Tube Thickness | 3-12mm |
| SA213 T23 Tube Origin | European, Japanese, Korean, US, Russian, New Zealandn (Strictly No Chinese Material) |
| SA213 T23 Tube Tolerance | Cold drawn pipe: +/-0.1mm Cold rolled pipe: +/-0.05mm |
| Craft | Cold rolled and Cold drawn |
| SA213 T23 Tube Type | Seamless / ERW / Welded / Fabricated |
| SA213 T23 Tube available in Form of | Round, Square, Rectangular, Hydraulic Etc. |
| SA213 T23 Tube Length | Standard Double & In Cut length also. |
| SA213 T23 Tube End | Plain End, Beveled End, Treaded |
| Specialized in | ASME SA213 T23 Boiler Tube, SA213 T23 Heater Tube, SA213 T23 Heat Exchanger Tube |
| SA213 gr T23 Additional Testing | NACE MR 0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, H2 SERVICE, IBR, etc. |
| SA213 grade T23 Tube Application | Seamless Ferritic Alloy Steel Tube for High-Temperature Service |
| Grade | C≤ | Mn | P≤ | S≤ | Si≤ | Mo |
|---|---|---|---|---|---|---|
| T23 | 0.04~0.10 | 0.1~0.6 | 0.03max | 0.01 max | 0.5 max | 0.05~0.30 |
| Grade | Tensile Strength, MPa | Yield Strength, MPa | Elongation, % | Hardness, HB |
|---|---|---|---|---|
| T23 | 510 min | 400 min | 20 min | 220 max |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Outside Diameter | OD Tolerance | WT Tolerance | Ovality Tolerance | Cut Length Tolerance |
| OD≤ 12, 7 mm | ± 0, 13 mm | ± 15 % | – | + 3, 18 mm, – 0 mm |
| 12, 7 mm < OD ≤ 38, 1 mm | ± 0, 13 mm | ± 10 % | max, 1, 65 mm | + 3, 18 mm, – 0 mm |
| 38, 1 mm < OD ≤ 88, 9 mm | ± 0, 25 mm | ± 10 % | max, 2, 41 mm | + 4, 76 mm, – 0 mm |
Jaxon Steel is a leading manufacturer and distributor of high-quality Alloy Steel T23 Tubing in Hamilton, New Zealand. We offer premium steel materials and a wide range of products, including Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel. Our extensive inventory includes Tubes, Pipes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Committed to timely delivery and exceptional customer service, we utilize only the finest raw materials to ensure superior performance in industrial applications with demanding specifications. Contact us today for all your Alloy Steel T23 Tubing needs!
You’ll typically find Alloy Steel T23 Tubing playing a crucial role in the high-heat sections of power generation plants, especially within superheater and reheater tubes in boilers. Its ability to perform reliably under prolonged exposure to intense heat and pressure makes it a go-to choice for these critical components. Beyond energy production, its durability also lends itself to various processing systems in petrochemical plants and other industrial settings where temperature resilience is non-negotiable for both safety and efficiency.
Latham Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Hamilton, New Zealand.
