Located in the heart of Hamilton, Latham Steel has built a reputation as a trusted partner for industry, supplying high-performance materials like Alloy Steel T9 Tubing. We understand that the success of your projects relies on the integrity of your components, which is why we are committed to providing tubing that meets the most demanding specifications. Our team is proud to support local and international engineering efforts with reliable, quality products sourced and supplied with genuine expertise.
Alloy Steel T9 is defined by its specific composition, primarily chromium and molybdenum, which give it a distinct edge. This combination results in exceptional strength and notable resistance to creep, meaning it performs reliably under high stress and intense heat. These mechanical properties allow T9 tubing to maintain its structural integrity in challenging environments where ordinary steel would quickly fail, making it a cornerstone for high-temperature systems.
| ASTM A213 T9 Specification & Standard | ASTM A213 T9, ASME SA213 T9 (with IBR Test Certificate) |
|---|---|
| SA 213 Gr T9 Specification | ASTM A213 & ASTM A209 BS/3059/ 90/ Part II/ 620 & 622 DIN/ 17175/ 13CrMo44 DIN/ 17175/ 10CrMo910 DIN/ 17175/ 15Mo3 |
| T9 Steel Tube Sch. & Swg. | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg., 3.6 mm Thk |
| A213 Grade T9 Tubing Size | 6.35 mm OD to 101.6 mm OD |
| SA213 Grade T9 Pipe Thickness | 3-12mm |
| ASTM A213 Grade T9 Tube available in Form of | Round, Square, Rectangular, Hydraulic Etc. |
| Craft | Cold rolled and Cold drawn |
| SA213 Grade T9 Tube Type | Seamless / ERW / Welded / Fabricated |
| A213 Grade T9 Tube Tolerance | Cold drawn pipe: +/-0.1mm Cold rolled pipe: +/-0.05mm |
| T9 Steel Grade Material Origin | European, Japanese, Korean, US, Russian, New Zealandn (Strictly No Chinese Material) |
| SA213 T9 Steel Tube Length | Standard Double & In Cut length also. |
| T9 Steel Grade Tube End | Plain End, Beveled End, Treaded |
| SA213 Grade T9 Additional Testing | NACE MR 0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, H2 SERVICE, IBR, etc. |
| Specialized in |
|
| SA213 T9 Steel Tube Application & uses | Seamless Ferritic Alloy Steel Tube for High-Temperature Service |
| Grade | C≤ | Mn | P≤ | S≤ | Si≤ | Mo |
|---|---|---|---|---|---|---|
| SA213 T9 Composition |
0.15 max |
0.30~0.60 |
0.025 |
0.025 |
0.25-1.0 |
0.90~1.10 |
| Grade | Tensile Strength, MPa | Yield Strength, MPa | Elongation, % | Hardness, HB |
|---|---|---|---|---|
| T9 | 415 min | 205 min | 30 min | 179 max |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Outside Diameter | OD Tolerance | WT Tolerance | Ovality Tolerance | Cut Length Tolerance |
| OD≤ 12, 7 mm | ± 0, 13 mm | ± 15 % | – | + 3, 18 mm, – 0 mm |
| 12, 7 mm < OD ≤ 38, 1 mm | ± 0, 13 mm | ± 10 % | max, 1, 65 mm | + 3, 18 mm, – 0 mm |
| 38, 1 mm < OD ≤ 88, 9 mm | ± 0, 25 mm | ± 10 % | max, 2, 41 mm | + 4, 76 mm, – 0 mm |
Jaxon Steel is a trusted manufacturer and supplier of premium Alloy Steel T5 Tubing in Hamilton, New Zealand. We specialize in high-quality steel materials and offer a diverse range of products, including Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel. Our extensive inventory includes Tubes, Pipes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. With a commitment to timely delivery and outstanding customer service, we use only the finest raw materials to ensure exceptional performance in demanding industrial applications. Contact us today for all your Alloy Steel T5 Tubing needs!
You’ll typically find T9 tubing at work in the most demanding industrial settings, especially within power generation plants and refinery operations. Its primary role is in superheater and reheater piping systems, where it reliably contains high-pressure steam at extremely elevated temperatures. This makes it indispensable for boilers and heat exchangers, ensuring efficient and safe energy transfer. Essentially, it’s the material of choice for any application requiring long-term durability against heat and pressure.
Latham Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Hamilton, New Zealand.
