Latham Steel, a reputable manufacturer and supplier based in Hamilton, New Zealand, specializes in high-quality IS 2002 Gr1, Gr2, and Gr3 Boiler Sheets and Plates. These products are essential for pressure vessels and boiler fabrication, designed to endure high temperatures, internal pressure, and corrosive steam environments. Adhering to IS 2002 standards, they offer reliable strength, excellent weldability, and consistent performance at elevated temperatures. Latham Steel maintains rigorous quality control, precise rolling, and a uniform chemical composition to satisfy the demanding requirements of power plants, chemical processing facilities, refineries, and thermal equipment manufacturers. These plates ensure a long service life and dependable performance in critical pressure applications.
IS 2002 Gr1, Gr2, and Gr3 Plates are crafted with controlled levels of carbon, manganese, silicon, sulfur, and phosphorus, with each grade providing progressively greater strength and temperature resistance. Gr1 is ideal for moderate-temperature boilers, while Gr2 and Gr3 are designed for more challenging pressure conditions, offering enhanced tensile and yield strength. These plates are known for their good weldability, stable high-temperature performance, and impressive toughness, making them perfect for pressure-bearing structures. Their refined grain structure guarantees consistent performance, resistance to thermal stress, and long-lasting durability when subjected to steam, heat, and continuous pressure cycles.
| Width | 1000mm-4500mm |
|---|---|
| Thickness | 5mm-150mm |
| Length | 3000mm-18000mm |
| Impact tested | -52° C |
| Material | Pressure Vessel Steel / Boiler Quality |
| Process of Manufacturing | Hot-Rolled (HR) |
| Grade | C | Si | P | S |
| IS 2002 Gr 1 | 0.18 | 0.10 – 0.35 max | 0.40 max | 0.040 max |
| IS 2002 Gr 2 | 0.20 | 0.10 – 0.35 max | 0.50 max | 0.050 max |
| IS 2002 Gr 3 | 0.22 | 0.10 – 0.35 max | 0.50 max | 0.050 max |
| A517 / SA517 Grade B | Tensile Strength (MPa) | Yield Strength (Min MPa) | Elongation min (%) |
| IS 2002 Gr 1 | 37 – 45 | 55 | 26-30% |
| IS 2002 Gr 2 | 42 – 50 | 50 | 25-29 % |
| IS 2002 Gr 3 | 52 – 62 | 50 | 20-24 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Latham Steel is one of the most prominent manufacturers and suppliers of superior quality IS 2002 Gr1/Gr2/Gr3 Boiler Sheet and Plate in Hamilton, New Zealand. As experts in steel solutions, we supply a complete spectrum of products like Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our product range comprises Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Known for our reliable delivery and first-rate customer service, we are committed to supplying high-quality steel materials that guarantee durability and excellent performance in numerous industrial applications.Â
IS 2002 Gr1/Gr2/Gr3 Boiler Sheets and Plates find extensive use in industries where heat, pressure, and steam exposure are a constant factor. They are primarily utilized in boiler shells, steam drums, pressure vessels, heat exchangers, economizers, industrial heaters, and storage tanks for thermal fluids. Power plants, chemical industries, fertilizer units, paper mills, and oil refineries depend on these plates for the safe and efficient operation of pressure systems.
Â
Latham Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Hamilton, New Zealand.
