From the heart of Hamilton’s industrial landscape, Latham Steel has built a reputation as a trusted manufacturer and supplier, providing robust solutions for demanding projects. We are particularly proud of our expertise with Carbon Steel WPHY 80 Pipe Fittings, components engineered to meet the challenges of high-pressure, high-temperature environments. Our commitment goes beyond supply; we offer reliable, locally-backed service and a deep understanding of the precise standards required for critical infrastructure, ensuring your systems are built on a foundation of uncompromising quality and integrity.
Carbon Steel WPHY 80 Pipe Fittings are defined by their exceptional strength and resilience, properties forged from a precise chemical composition. The “80” denotes a minimum yield strength of 80,000 psi, which is achieved through specific alloying elements and controlled heat treatment. This process enhances toughness and durability, making these fittings capable of withstanding significant internal pressures and impact loads. In essence, the material is engineered to be incredibly tough, resisting deformation and failure even under the strenuous conditions found in heavy industrial applications.
| Specifications: | ASTM A860 / ASME SA860 |
|---|---|
| Size: | Seamless Butt Weld Fittings : 1/2″ – 10″, Welded Butt Weld Fittings : 1/2″ – 48″ |
| Dimensions: | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1800, BS10 |
| Thickness: | 5s, 10s, 40s, 80s, 10, 20, 40, STD, 80, 80, XS, 100, 120, 140, 180, XXS available with NACE MR 01-75 |
| Bending Radius: | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom ASTM A860 Gr WPHY 80 Pipe Fitting |
| Type: | Seamless / Welded / Fabricated |
| Grade | C | Mn | P | S | Si | Ni | Cr | Mo | Cu | Ti | V | cb | AI | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ASTM WPHY 80 | 0.20 | 1.00-1.45 | 0.03 | 0.01 | 0.15-0.40 | 0.50 | 0.30 | 0.25 | 0.35 | 0.05 | 0.10 | 0.04 | 0.06 | |
| Element | ASTM WPHY 80 | |
|---|---|---|
| Tensile Strength (mpa) | 485 | |
| Yield Strength (mpa) | 580 | |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Nominal Pipe Size | Outside Diameter | Caps | Straight Tees | Straight Crosses | Stub Ends | |||
| inch | mm | inch | Length (inch) | Center to End (inch) | Center to End (inch) | Lap Diameter (inch) | Long Length (inch) | Short Length (inch) |
| 1/2 | 21.3 | 0.840 | 1 | 1 | – | 1 3/8 | 3 | 2 |
| 3/4 | 26.7 | 1.050 | 1 | 1 1/8 | – | 1 11/16 | 3 | 2 |
| 1 | 33.4 | 1.315 | 1 1/2 | 1 1/2 | 1 1/2 | 2 | 4 | 2 |
| 1 1/4 | 42.2 | 1.660 | 1 1/2 | 1 7/8 | 1 7/8 | 2 1/2 | 4 | 2 |
| 1 1/2 | 48.3 | 1.900 | 1 1/2 | 2 1/4 | 2 1/4 | 2 7/8 | 4 | 2 |
| 2 | 60.3 | 2.375 | 1 1/2 | 2 1/2 | 2 1/2 | 3 5/8 | 6 | 2 1/2 |
| 2 1/2 | 73.0 | 2.875 | 1 1/2 | 3 | 3 | 4 1/8 | 6 | 2 1/2 |
| 3 | 88.9 | 3.500 | 2 | 3 3/8 | 3 3/8 | 5 | 6 | 2 1/2 |
| 3 1/2 | 101.6 | 4.000 | 2 1/2 | 3 3/4 | 3 3/4 | 5 1/2 | 6 | 3 |
| 4 | 114.3 | 4.500 | 2 1/2 | 4 1/8 | 4 1/8 | 6 3/16 | 6 | 3 |
| 5 | 141.3 | 5.563 | 3 | 4 7/8 | 4 7/8 | 7 5/16 | 8 | 3 |
| 6 | 168.3 | 6.625 | 3 1/2 | 5 5/8 | 5 5/8 | 8 1/2 | 8 | 3 1/2 |
| 8 | 219.1 | 8.625 | 4 | 7 | 7 | 10 5/8 | 8 | 4 |
| 10 | 273.1 | 10.750 | 5 | 8 1/2 | 8 1/2 | 12 3/4 | 10 | 5 |
| 12 | 323.9 | 12.750 | 6 | 10 | 10 | 15 | 10 | 6 |
Latham Steel is a top manufacturer and supplier of high-quality Carbon Steel WPHY 80 Pipe Fittings products in Hamilton, New Zealand. Specializing in steel solutions, we provide a wide range of products, including Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel. Our offerings include Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates. Known for our reliable delivery and superior customer service, we are committed to offering top-tier steel materials that ensure durability and performance across a wide range of industrial applications. We strive to meet the highest standards, making us a trusted partner for all your steel needs.
The exceptional strength of WPHY 80 fittings makes them indispensable in industries where safety and reliability are non-negotiable. You will find them forming the backbone of high-pressure piping systems in oil and gas extraction, petrochemical plants, and power generation facilities. They are the preferred choice for critical connections in refineries, offshore platforms, and any application involving potentially hazardous fluids where a failure is not an option. Essentially, these fittings are deployed wherever the demands of the system call for a superior level of performance and safety assurance.
Latham Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Hamilton, New Zealand.
