From the heart of Hamilton’s industrial landscape, Latham Steel proudly stands as a manufacturer and supplier you can count on. We specialise in providing high-quality steel solutions, and our Carbon Steel EN 10083-2 Grade C22R Pipe is a prime example of this commitment. Known for its excellent balance of strength and workability, this pipe grade is a fundamental component for countless projects, offering the reliable performance that New Zealand’s engineering and construction sectors have trusted for years.
This particular grade, C22R, gets its dependable nature from a straightforward yet effective composition. It’s a carbon steel with a moderate carbon content, providing a solid foundation for its mechanical properties. When heat-treated, it achieves a good tensile strength, making it resilient under pressure, while also maintaining a commendable level of ductility. This means it can be shaped and welded with relative ease, offering fabricators a material that is both strong and adaptable to their needs.
| Specification | Details |
|---|---|
| Material | EN 10083-2 Grade C22R Carbon Steel |
| Product | Seamless Pipes and Tubes |
| Carbon Content | Max 0.20% |
| Manganese Content | 0.50% – 1.40% |
| Characteristics | – Low-Cost: Cost-effective option for low-carbon steel pipes – Formability: Easy to form and shape – Surface Hardness: Not as hard as high carbon steel pipes, but can be – increased through carburizing |
| Standard | Manufactured as per EN 10083-2 specification |
| Commercial Reference | Referred to as CS (carbon steel) pipes or MS (mild steel) pipes |
| Carbon | Silicon | Manganese | Phosphorous | Sulphur | Molybdenum | Nickel | Chromium | Copper | Others |
| 0.17-0.24 | max 0.40 | 0.40-0.70 | 0.045 | 0.045 | max 0.10 | max 0.40 | max 0.40 | – | – |
| Yield Strength | Tensile Strength | Elongation A5 min | |||
|---|---|---|---|---|---|
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage |
|  |  | 430 | – | – | 24 |
| DIN | EN | BS | NFA | ASTM | ASME |
|---|---|---|---|---|---|
| DIN 17204 Grade Cm22 | EN 10083-2 Grade C22R | – | ASTM A519 Grade 1021 | ASME SA 519 Grade 1021 | – |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a trusted manufacturer and supplier of high-quality Carbon Steel EN 10083-2 Grade C22R Pipe products in Hamilton, New Zealand. Specializing in premium steel materials, we offer a comprehensive range, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our extensive inventory features Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Committed to reliable delivery and exceptional customer service, Jaxon Steel provides top-grade materials that ensure superior performance across various industrial applications. Trust Jaxon Steel for all your Carbon Steel EN 10083-2 Pipe needs.
| Execution | Size Range | OD Tolerance | Wall tolerance |
|---|---|---|---|
| Hot-rolled Tube | OD – 80 mmOD > 80 mmWall < 12 mmWall – 12 mm | ± 0.4 mm± 0.5 % of OD | ± 0.7 mm± (5 % x wallthickness + 0.1 mm |
| Hot-rolled peeled tube | All sizesWall < 12 mmWall – 12 mm | + 0.25/- 0 mm | ± 0.8 mm± (5 % x wall thickness+ 0.2 mm) |
| Cold Worked tubecold-rolled or cold-drawn | OD < 40 mmOD 40 – 80 mmOD > 80 Wall Thickness < 6 mm Wall Thickness6 – 8 mm Wall Thickness > 8 | + 0.30/- 0 mm*+ 0.35/- 0 mm*+ 0.40/- 0 mm* | ± 0.30 mm± 0.35 mm± 0.40 mm |
The balanced characteristics of the C22R pipe make it incredibly versatile across a wide range of uses. You’ll commonly find it forming the backbone of general structural frameworks and in mechanical engineering applications where reliability is key. It’s perfectly suited for creating various machinery components, automotive parts, and even certain hydraulic systems. Its workability also makes it a popular choice for general fabrication projects, serving everything from agricultural equipment to essential supports within construction sites, proving its worth in both everyday and demanding environments.
Latham Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Hamilton, New Zealand.
