For over three decades, Latham Steel in Hamilton has been a trusted name, supplying robust and reliable materials directly from the heart of New Zealand’s industry. We take pride in offering the dependable Carbon Steel A524 Pipe, a product engineered for demanding environments. Our team understands the critical nature of your projects, which is why we ensure this pipe meets the highest standards for performance and durability, providing you with a solution you can count on for the most challenging applications.
The strength of A524 Pipe comes from its consistent chemical composition, primarily iron and carbon, balanced to deliver excellent toughness. This specific blend gives the pipe its signature mechanical properties, including a high yield strength that allows it to withstand significant pressure without deforming. It maintains good ductility, meaning it can bend slightly under stress rather than crack, a crucial feature for safety and longevity in high-stakes systems where reliability is absolutely essential.
| Carbon | Silicon | Manganese | Phosphorous | Sulphur | Molybdenum | Nickel | Chromium | Copper | Others |
|---|---|---|---|---|---|---|---|---|---|
| max 0.21 | 0.10 – 0.40 | 0.90 – 1.35 | 0.035 | 0.035 | – | – | – | – | – |
| Yield Strength | Tensile Strength | Elongation A5 min | |||
|---|---|---|---|---|---|
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage |
| 414 | 586 | 60 | 30 | ||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Pipe Size (Nominal) | Wall Thickness | Wt. Lbs. Per Foot |
|---|---|---|
| 1/2 | .065 | .5383 |
| 3/4 | .065 | .6838 |
| 1 | .065 | .8678 |
| 1-1/4 | .065 | 1.107 |
| 2 | .065 | 1.604 |
| 2-1/2 | .083 | 2.475 |
| 3 | .083 | 3.029 |
| 3-1/2 | .083 | 3.472 |
| 4 | .083 | 3.915 |
| 4-1/2 | .247 | 12.54 |
| 5 | .109 | 6.349 |
| 6 | .109 | 7.585 |
| 7 | .301 | 23.54 |
| 8 | .109 | 9.914 |
| 9 | .342 | 33.91 |
| 10 | .134 | 15.19 |
| 11 | .375 | 45.56 |
| 12 | .165 | 22.18 |
| 14 | .250 | 36.71 |
| 16 | .250 | 42.05 |
| 18 | .250 | 47.39 |
| 20 | .250 | 52.73 |
| 20 | 1.969 | 379.2 |
| 24 | .250 | 63.41 |
Latham Steel is a top manufacturer and supplier of high-quality Carbon Steel A524 Pipe products in Hamilton, New Zealand. Specializing in steel solutions, we provide a wide range of products, including Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel. Our offerings include Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates. Known for our reliable delivery and superior customer service, we are committed to offering top-tier steel materials that ensure durability and performance across a wide range of industrial applications. We strive to meet the highest standards, making us a trusted partner for all your steel needs.
This pipe is a workhorse in industries where failure is not an option. You’ll find it forming the backbone of critical pressure vessels and high-temperature heat exchangers in power generation and chemical processing plants. It’s also essential in oil and gas refineries, safely transporting volatile substances. For engineers and project managers, its proven performance in these severe-service applications makes it the preferred choice for constructing infrastructure that demands unwavering integrity under immense pressure and heat.
Latham Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Hamilton, New Zealand.
