For over [number] years, Latham Steel in Hamilton has been a reliable partner for New Zealand industry, providing robust materials built to handle the toughest jobs. We are proud suppliers of high-performance Carbon Steel A106 Gr C Pipe, a product that embodies our commitment to quality and durability. This seamless pipe is engineered for demanding high-pressure and high-temperature environments, making it a trusted choice for critical infrastructure and industrial projects across the country, right from our base in the heart of the Waikato.
This particular grade of carbon steel achieves its robust character through a specific composition, primarily iron with carefully balanced additions of carbon, manganese, and silicon. This formula gives the A106 Gr C pipe excellent mechanical strength, allowing it to withstand significant internal pressure. It also maintains good ductility and can be easily welded and fabricated, offering both resilience and versatility for complex system designs. Its reliable performance under stress is a direct result of this carefully engineered combination of elements.
| Standard Specification | ASTM A 106, ASME SA 106 (Grade C) |
| Codes and Standards | ANSI, ASME, ASTM, API, SAE, BS, AGA, AWWA, ISO, DIN |
| Dimensions | ASME/ ANSI B36.10 / 19 |
| Standard Size | 1/2” NB to 36” NB (LSAW, SSAW, HSAW) |
| Wall Thickness | 3-12mm |
| Pipes schedules | SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS |
| Producing techniques | Seamless / ERW / Welded / Fabricated / CDW / EFW |
| Types | Round, Half Round, Square, Rectangular or Custom shape |
| Length | 3 to Max18 Meters or custom |
| End | Beveled End, Plain End, Treaded |
| Test Certificate | EN 10204 3.1 B |
| Grade | MFG. | C max | Mn* | P max | S max | Si min | Cr˟ max | Cu˟ max | Ni˟ max | Mo˟ max | V˟ max |
|---|---|---|---|---|---|---|---|---|---|---|---|
| C | SMLS | 0.35* | 0.29-1.06 | 0.035 | 0.035 | 0.10 | 0.40 | 0.40 | 0.40 | 0.15 | 0.08 |
| Grade | Process | Tensile Strength (MPa) Min | Yield Strength (MPa) Min | Elongation in 2” (%) MinimumLong. Strip Test | Elongation in 2” (%) MinimumTrans. Strip Test |
|---|---|---|---|---|---|
| C | SMLS | 70,000 [485] | 40,000 [275] | 30 | 16.5 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Minimal Pipes Size [DN Designator] | Under | Over | ||
| mm | in. | mm | in. | |
| 1/8 to 1-1/2 [6 to 40], incl | 0.4 | 1/64 (0.015) | 0.4 | 1/64 (0.015) |
| Over 1-1/2 to 4 [40 to 100], incl | 0.8 | 1/32 (0.031) | 0.8 | 1/32 (0.031) |
| Over 4 to 8 [100 to 200], incl | 0.8 | 1/32 (0.031) | 1.6 | 1/16 (0.062) |
| Over 8 to 18 [200 to 450], incl | 0.8 | 1/32 (0.031) | 2.4 | 3/32 (0.093) |
| Over 18 to 26 [450 to 650], incl | 0.8 | 1/32 (0.031) | 3.2 | 1/8 (0.125) |
| Over 26 to 34 [650 to 859], incl | 0.8 | 1/32 (0.031) | 4.0 | 5/32 (0.156) |
| Over 34 to 48 [850 to 1200], incl | 0.8 | 1/32 (0.031) | 4.8 | 3/16 (0.187) |
Latham Steel is a top manufacturer and supplier of high-quality Carbon Steel A106 Gr C Pipe products in Hamilton, New Zealand. Specializing in steel solutions, we provide a wide range of products, including Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel. Our offerings include Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates. Known for our reliable delivery and superior customer service, we are committed to offering top-tier steel materials that ensure durability and performance across a wide range of industrial applications. We strive to meet the highest standards, making us a trusted partner for all your steel needs.
The uses for this pipe are extensive, forming the hidden backbone of many essential systems. You’ll find it transporting steam, oil, and gas in power generation plants, and moving high-temperature fluids in refinery and petrochemical applications. It’s also ideal for high-pressure boiler feed systems and vital process piping in industrial facilities. Essentially, wherever there’s a need to safely convey fluids or gases under significant heat and pressure, A106 Gr C pipe provides a dependable and long-lasting solution for engineers and project managers.
Latham Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Hamilton, New Zealand.
