From the industrious heart of Hamilton, New Zealand, Latham Steel proudly supplies the backbone of modern maritime engineering: ABS AH36 shipbuilding steel sheet and plates. We understand that the integrity of a vessel begins with the quality of its materials, which is why we provide this high-strength steel to shipyards and fabricators who cannot compromise on safety or performance. Trust in Latham Steel for a reliable supply of the robust foundations needed to build structures that confidently face the relentless forces of the ocean.
This specific grade is a low-carbon alloy steel, carefully formulated with elements like manganese and phosphorus to achieve its notable strength. The “AH36” designation confirms its high yield strength of 36 ksi (or 355 MPa), ensuring exceptional toughness and resistance to impact, even in colder environments. Its excellent weldability is a key feature, allowing for efficient and secure construction of complex hull sections without compromising the material’s inherent durability under heavy loads and dynamic stresses.
STANDARD:Â ASTM A131, ASME SA131
PLATES QUALITY: AH 36 (Dead Soft Quality)
THICKNESS: 3/16″ – 4″, 4-60mm
WIDTH: 48″ – 120″, 2000 / 2500 / 3000mm
LENGTH: 96″ – 480″, 6000 / 8000 / 10000 / 12000 mm
| C | Si | Mn | P | S | Cr | Mo | Ni | Cu | Cb | V |
| 0.18 | 0.10/0.50 | 0.90/1.60 | 0.035 | 0.035 | 0.20 | 0.08 | 0.40 | 0.35 | 0.02/0.05 | 0.05/0.10 |
| Grade | Re | Rm | Elongation | Â |
| A50mm | A200mm | |||
| MPan | MPa | % | % | |
| AH36 | 355 | 490/620 | 22 | 19 |
| DNV | GL | LR | BV | CCS | NK | KR | RINA |
| NV A36 | GL A36 | LR A36 | BV AH36 | CCS A36 | KA36 | RA 36 | RINA AH36 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Latham Steel is one of the most prominent manufacturers and suppliers of superior quality ABS AH36 Shipbuilding Steel Sheet and Plates in Hamilton, New Zealand. As experts in steel solutions, we supply a complete spectrum of products like Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our product range comprises Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Known for our reliable delivery and first-rate customer service, we are committed to supplying high-quality steel materials that guarantee durability and excellent performance in numerous industrial applications.Â
| theoretical weight | Thickness (mm) | Thickness (mm) | theoretical weight | ||
|---|---|---|---|---|---|
| Kg/m2 | Kg/ft2 | Kg/m2 | Kg/ ft2 | ||
| 47.10 | 4.376 Kg/ft2 | 6 | 25 | 196.25 | 18.962 Kg/ ft2 |
| 54.95 | 5.105 Kg/ft2 | 7 | 26 | 204.10 | 20.420 Kg/ ft2 |
| 86.35 | 8.751 Kg/ft2 | 11 | 32 | 251.20 | 25.525 Kg/ ft2 |
| 172.70 | 16.044 Kg/ft2 | 22 | 50 | 392.50 | 36.464 Kg/ ft2 |
| 62.80 | 5.834 Kg/ft2 | 8 | 28 | 219.80 | 21.879 Kg/ ft2 |
| 157.00 | 14.586 Kg/ft2 | 20 | 48 mm | 376.80 | 35.006 Kg/ ft2 |
| 78.50 | 7.293 Kg/ft2 | 10 | 30 mm | 235.50 | 23.337 Kg/ ft2 |
| 94.20 | 10.21 Kg/ft2 | 12 | 34 mm | 266.90 | 26.254 Kg/ ft2 |
| 125.60 | 11.669 Kg/ft2 | 16 | 40 mm | 314.00 | 29.172 Kg/ ft2 |
| 141.30 | 13.127 Kg/ft2 | 18 | 45 mm | 353.25 | 32.818 Kg/ ft2 |
| 109.90 | 10.939 Kg/ft2 | 14 | 35 mm | 274.75 | 27.713 Kg/ ft2 |
| 188.40 | 18.232 Kg/ft2 | 24 | |||
| Max. width | Thickness |
|---|---|
| Grade A | From to up to |
| 1370 | 1.70 to 1.80 |
| 1280 | 1.60 to 1.70 |
| 1440 | 1.80 to 1.90 |
| 1520 | 1.90 to 2.00 |
| 1170 | 1.49 to 1.60 |
| 2070 | 12.70 to 20.00 |
| 1590 | 2.00 to 2.20 |
| 1730 | 2.20 to 2.40 |
| 1880 | 2.60 to 2.80 |
| 1960 | 2.80 to 3.12 |
| 1800 | 2.40 to 2.60 |
| 2070 | 3.12 to 12.70 |
The primary use for ABS AH36 steel is, as the name implies, in the construction of ship hulls, decks, and other critical structural components for commercial vessels, naval ships, and offshore platforms. Its high strength-to-weight ratio is crucial for building larger, more fuel-efficient ships that can withstand the immense pressures of heavy cargo and punishing sea conditions. Beyond shipbuilding, this steel is also trusted for heavy-duty applications in bridge building, mining equipment, and any project demanding superior load-bearing capacity and resilience.
Latham Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Hamilton, New Zealand.
