Latham Steel, a well-respected manufacturer and supplier located in Hamilton, New Zealand, specializes in high-quality A36 Steel Sheets and Plates designed for dependable structural performance and versatile fabrication needs. Renowned for its consistent quality, precise thickness, and robust mechanical stability, Latham Steel guarantees that its A36 plates comply with international standards for construction, engineering, and general manufacturing. A36 steel is favored for its excellent weldability, machinability, and formability, making it a top choice for builders and fabricators throughout New Zealand. With a reliable supply chain, rigorous quality control, and a customer-centric approach, Latham Steel provides durable, cost-effective A36 steel solutions for a variety of industrial projects.
A36 Steel Sheets and Plates are crafted from low-carbon steel, containing around 0.25% carbon along with carefully controlled levels of manganese, silicon, phosphorus, and sulfur. This specific composition results in a balanced combination of strength, ductility, and exceptional weldability. The mechanical properties include solid tensile strength, dependable yield strength, and impressive toughness, making it suitable for structural and fabrication tasks. The material is easy to shape, bends effortlessly, and holds its stability under moderate loads. Its predictable behavior during machining and welding is what makes A36 a popular choice for general-purpose structural steel.
| Item | Carbon Structural Steel Plates – ASTM A36 |
|---|---|
| Thickness | 5mm-150mm |
| Width | 1000mm-4500mm |
| Length | 3000mm-18000mm |
| Grade | C | Si | Mn | P | S |
| ASTM A36 | 0.25 max. | 0.4 max. | 0.8-1.2 | 0.035 max. | 0.035 max. |
| Tensile strength, kis [MPa] | Yield strength, min, kis [MPa] | Elongation in 8 in. [200 mm], min, % | Elongation in 2 in. [50 mm], min, % |
| 58-80 [400-550] | 36 [250] | 20 | 23 |
| EN | GB | USA | BS | ISO | JIS | IS |
| S235J2G4, Fe360D2 | Q235D | A36 | 40EE | Fe 360B | SM 400 A | IS 226 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Latham Steel is one of the most prominent manufacturers and suppliers of superior quality A36 Steel Sheet and Plate in Hamilton, New Zealand. As experts in steel solutions, we supply a complete spectrum of products like Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our product range comprises Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Known for our reliable delivery and first-rate customer service, we are committed to supplying high-quality steel materials that guarantee durability and excellent performance in numerous industrial applications.Â
| Thickness (Inches) | Tolerance Over Specified Thickness, For Widths Given, in Inches | |||||||||
| 48 to 59 | 144 to 167 | Thru 47 | 60 to 71 | 96 to 107 | 72 to 83 | 132 to 143 | 120 to 131 | 108 to 119 | 84 to 95 | |
| To under 1/4 | 0.030 | – | 0.030 | 0.030 | 0.030 | 0.030 | 0.040 | 0.030 | 0.030 | 0.030 |
| 1/4 to under 5/16 | 0.030 | – | 0.030 | 0.030 | 0.030 | 0.030 | 0.040 | 0.040 | 0.030 | 0.030 |
| 2 to under 3 | 0.090 | 0.150 | 0.090 | 0.090 | 0.110 | 0.100 | 0.140 | 0.130 | 0.120 | 0.100 |
| 3/8 to under 5/8 | 0.030 | 0.060 | 0.030 | 0.030 | 0.030 | 0.030 | 0.050 | 0.040 | 0.040 | 0.030 |
| 5/16 to under 3/8 | 0.030 | 0.050 | 0.030 | 0.030 | 0.030 | 0.030 | 0.040 | 0.040 | 0.030 | 0.030 |
| 6 to under 10 | 0.240 | 0.270 | 0.230 | 0.240 | 0.240 | 0.240 | 0.240 | 0.240 | 0.240 | 0.240 |
| 3/4 to under 1 | 0.030 | 0.070 | 0.030 | 0.030 | 0.040 | 0.030 | 0.060 | 0.050 | 0.050 | 0.040 |
| 1 to under 2 | 0.060 | 0.110 | 0.060 | 0.060 | 0.070 | 0.060 | 0.100 | 0.100 | 0.080 | 0.060 |
| 3 to under 4 | 0.110 | 0.150 | 0.110 | 0.110 | 0.130 | 0.110 | 0.140 | 0.140 | 0.140 | 0.110 |
| 4 to under 6 | 0.150 | 0.200 | 0.150 | 0.150 | 0.150 | 0.150 | 0.150 | 0.150 | 0.150 | 0.150 |
| ASTM | Thickness (mm) | Weight (kg/m) |
| ASTM A36 | 3 mm | 23.55 kg |
| 4 mm | 31.4 kg | |
| 5 mm | 39.25 kg | |
| 6 mm | 47.1 kg | |
| 8 mm | 62.8 kg | |
| 10 mm | 78.5 kg | |
| 12 mm | 94.2 kg | |
| 16 mm | 125.6 kg | |
| 20 mm | 157 kg | |
| 22 mm | 172.7 kg | |
| 25 mm | 196.25 kg | |
| 28 mm | 219.8 kg | |
| 32 mm | 251.2 kg | |
| 36 mm | 282.6 kg | |
| 40 mm | 314 kg | |
| 45 mm | 353.25 kg | |
| 50 mm | 392.5 kg | |
| 55 mm | 431.75 kg | |
| 60 mm | 471 kg | |
| 65 mm | 510 kg | |
| 70 mm | 549.5 kg | |
| 75 mm | 588.75 kg | |
| 80 mm | 628 kg | |
| 90 mm | 706.5 kg | |
| 100 mm | 785 kg |
| TYPE | ALLOY | IMPERIAL SIZES IN STOCK | Â | Â |
|---|---|---|---|---|
| Â | Â | Thickness | Length | Width |
| Coil | ASTM A36 | 1/4 Inch, 3/16 Inch, 3/8 Inch, 5/16 Inch, 1/2 Inch, 7/16 Inch | Any | 60 Inch, 48 Inch,72 Inch |
| Cut to Length | 3/16 Inch to 1/2 Inch | Any | 84 Inch to 96 Inch | |
| Â | 3/16 Inch to 1/2 Inch | Any | 96 Inch, 84 Inch | |
| Hot Rolled (Strip Mill) | 3/8 Inch to 12 Inch | 240 Inch – 480 Inch | 72 Inch to 144 Inch | |
| Discrete (Mill Rolled) | 1/4 Inch, 3/16 Inch, 5/16 Inch | 240 Inch – 480 Inch | 84 Inch to 120 Inch |
A36 Steel Sheets and Plates find extensive use in construction, fabrication, and general engineering due to their versatility and ease of processing. Typical applications include building frames, support beams, base plates, brackets, bridges, ladders, and various structural components. Fabricators also utilize A36 steel for machinery parts, storage tanks, frames, platforms, trailers, and agricultural equipment. Its outstanding weldability and formability make it perfect for custom fabrication projects. A36 continues to be a cost-effective and reliable material for industrial, commercial, and structural applications.
Â
Â
Latham Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Hamilton, New Zealand.
