Latham Steel, a reputable manufacturer and supplier based in Hamilton, New Zealand, specializes in high-quality SA 516 GR.65N NACE HIC Plates designed for sour-service environments where hydrogen-induced cracking (HIC) poses a significant risk. These normalized pressure-vessel plates adhere to strict ASME and NACE standards, making them perfect for equipment that deals with hydrogen sulfide (H₂S) and other corrosive media. With a commitment to exceptional toughness, excellent weldability, and consistent material reliability, Latham Steel employs rigorous quality control and certified testing. Commonly found in refineries, petrochemical plants, and gas processing facilities, SA 516 GR.65N NACE HIC Plates deliver reliable performance in high-pressure, safety-critical industrial settings.
SA 516 GR.65N NACE HIC Plates are crafted from fine-grained carbon steel, featuring controlled amounts of carbon, manganese, silicon, and trace alloying elements to boost strength and crack resistance. These plates undergo a normalization process to enhance toughness, uniformity, and resistance to brittle fractures. They showcase impressive tensile and yield strength, outstanding notch toughness, and robust resistance to hydrogen-induced cracking and sulfide stress cracking. Their mechanical properties remain stable even under fluctuating temperatures and high-pressure conditions. With good weldability and ductility, these plates can be safely fabricated for sour-service pressure equipment.
| Grade | ASME SA 516 GR.65N Boiler and Pressure Vessel Steel Plates |
|---|---|
| Width | 1000mm-4500mm |
| Thickness | 5mm-150mm |
| Length | 3000mm-18000mm |
| Supply Condition | As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement. |
| Impact tested | 52° C |
| Tempering | Notch toughness can be improved by quenched cooling from hot rolling or normalizing by the supplier. If such a faster cooling rate is agreed upon between purchaser and supplier then the steel is also to be tempered at 1200 F. |
| Applications | Used for weld fabrication of pressure vessels that require improved notch toughness for lower than ambient temperature service. |
| Process of Manufacturing | Hot-Rolled (HR) |
| C | Si | Mn | P | S | Al | Cr | Cu | Ni | Mo | Nb | Ti | V |
| 0.08/0.20 | 0.4 | 0.9/1.5 | 0.03 | 0.03 | 0.02 | 0.3 | 0.3 | 0.3 | 0.08 | 0.01 | 0.03 | 0.02 |
| Tensile strength (ksi) | Tensile strength (MPa) | Yield strength (ksi) | Yield strength (MPa) | Elongation in 200mm (min)(%) | Elongation in 50mm (min) (%) |
| 65-85 | 450-585 | 35 | 240 | 19 | 23 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| British Standard | European Norm | ASTM/ASME | DIN |
| BS1501-224-460A/B | EN10028 P295GH | A/SA516 – Grade 65 | DIN 17155 17 MN 4 |
Jaxon Steel is a trusted manufacturer and supplier of high-quality SA 516 GR.65N NACE HIC Plates in Hamilton, New Zealand. We specialize in premium steel products, including Alloy Steel, Carbon Steel, Mild Steel and Galvanized Steel, with a strong focus on Carbon Steel Sheet and Plates. Our extensive inventory also includes Pipes, Tubes, Flanges, Forged Fittings and Bars. Committed to fast delivery and exceptional customer service, we use only the finest raw materials to ensure superior strength, durability and performance for critical industrial applications. Contact us today for all your SA 516 GR.65N NACE HIC Plates needs!
SA 516 GR.65N NACE HIC Plates find extensive use in industries that manage H₂S-containing fluids and corrosive environments. Key applications include pressure vessels, separators, heat exchangers, storage tanks, boilers, and gas-processing equipment in refineries, petrochemical facilities, and offshore operations. These plates are crucial for sour-service applications where safeguarding against hydrogen-induced cracking is essential for both safety and regulatory compliance. Their remarkable toughness and corrosion resistance make them a reliable choice for demanding industrial environments.
Latham Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Hamilton, New Zealand.
