From the heart of Hamilton’s industrial landscape, Latham Steel stands as a trusted manufacturer and supplier, providing robust solutions for New Zealand’s toughest projects. We specialise in EN 9 sheet and plate, a high-carbon steel known for its exceptional durability and strength. Our commitment lies in delivering material that meets the precise demands of local industry, ensuring reliability from our yard directly to your worksite, backed by deep technical knowledge and a focus on building lasting partnerships.
This high-carbon steel is defined by its composition, primarily iron with a significant carbon content that gives it notable hardness. Through careful heat treatment, it develops impressive mechanical properties, achieving a high tensile strength and excellent wear resistance. This process allows it to be hardened to a degree that makes it far more durable than milder steels, though it retains a degree of machinability in its annealed state, offering a versatile balance for fabrication.
Grade : EN9 Low Alloy Steel Plate
Thickness : from 3mm up to as thick as 150mm
Length :3000mm-18000mm
Supply Condition : As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement.
Impact tested : -52° C
Process of Manufacturing : Hot-Rolled (HR)
| Â Grade | Cr | C | Ni | Si | S | Mn | P | Mo |
| EN – 9 | – | .50 – .60 | – | .05 – .35 | .040 MAX | .50 – .80 | .040 MAX | – |
| Heat Treatment | Condition Tons/SQ.inch | Tensile Stress RE MPA | RP0.2 MPA | A min on 5.65so | Impac | Hardness HB | Limited Ruling Section mm | |
| IZODFT.L.b | KCV Joules | |||||||
| Normalise | 45 | 700 | – | 12 | – | – | 201-255 | 63 |
| 39 | 600 | – | 13 | – | – | 170/223 | 250 | |
| R | 45/55 | 700/850 | 385 | 14 | – | – | 201/277 | 100 |
| S | 50/60 | 775/925 | 450 | 14 | – | – | 223/277 | 63 |
| T | 55/65 | 850/1000 | 555 | 12 | – | – | 248/302 | 19 |
| BS 970 1991 | BS 970 1955 EN | AISI/SAE | Werkstoff |
| 070M55 | EN9 | 1055 | 1.0535 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
The robustness of EN 9 sheet and plate makes it a favourite for demanding applications where wear and strength are critical. You’ll frequently find it fabricated into heavy-duty components like gears, shafts, and liners for mining and quarrying equipment. It’s also the material of choice for high-strength brackets, blades for agricultural machinery, and other parts that must withstand significant impact and abrasion, proving invaluable across construction, engineering, and manufacturing sectors throughout New Zealand.
Latham Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Hamilton, New Zealand.
