From the heart of Hamilton’s industrial landscape, Latham Steel has built a reputation for sourcing and supplying robust materials for demanding applications. We are proud to offer the distinguished ASME SA 387 Grade 5 Class 1 & 2 sheets and plates, a product line that embodies our commitment to strength and reliability. This material is specifically engineered to withstand high temperatures and corrosive environments, making it a cornerstone for critical projects across New Zealand and beyond, where failure is not an option and performance is paramount.
The strength of this material lies in its precise composition and mechanical properties. It is a chromium-molybdenum alloy steel, with these elements providing excellent resistance to oxidation and corrosion, particularly at elevated temperatures. The steel is designed for high tensile strength and good ductility, even under stress in hot conditions. The “Class 1” designation indicates a normalized heat treatment, while “Class 2” is normalized and tempered, offering slightly different mechanical property balances to suit specific design requirements and service conditions for pressure vessels.
| Standard | ASTM A387 / ASME SA387 |
|---|---|
| Width | 1000mm-3000mm |
| Thickness | 1.0mm – 200mm |
| Production | Hot-Rolled (HR) / Cold-Rolled (CR) |
| Grade | C | Si | Mn | P | S | Cr | Mo |
| A387 GR.5 CL.1 | 0.15 max | 0.55 max | 0.25-0.66 max | 0.035 max | 0.035 max | 3.90-6.10 max | 0.40-0.70 max |
| Grade | A387 GR.5 CL.1 | |||
| A387 GR.5 CL.1 | Thickness mm | Yield Min Mpa | Tensile Mpa | Elongation Min % |
| t≦50 | 205 | 415-585 | 18 | |
| 50<t≦200 | – | – | – | |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a trusted manufacturer and supplier of high-quality ASME SA 387 Grade 5 Class 1/2 Sheet and Plates​ in Hamilton, New Zealand. We specialize in premium steel products, including Alloy Steel, Carbon Steel, Mild Steel and Galvanized Steel, with a strong focus on Carbon Steel Sheet and Plates. Our extensive inventory also includes Pipes, Tubes, Flanges, Forged Fittings and Bars. Committed to fast delivery and exceptional customer service, we use only the finest raw materials to ensure superior strength, durability and performance for critical industrial applications. Contact us today for all your ASME SA 387 Grade 5 Class 1/2 Sheet and Plates​ needs!
When it comes to practical use, these sheets and plates are the material of choice for heavy-duty pressure vessels and boilers that operate in high-heat service. You will find them forming the core components of reactors, heat exchangers, and distillation columns within the petrochemical and power generation industries. Their ability to maintain integrity under extreme pressure and temperature makes them indispensable for building the infrastructure that drives essential sectors, ensuring safety and longevity in some of the most challenging operational environments imaginable.
