Latham Steel stands as a cornerstone of Hamilton’s industrial landscape, proudly supplying robust fastening solutions to New Zealand’s builders and manufacturers. Our commitment to quality shines through in products like our Alloy Steel Grade 8.8 bolts, engineered to meet the rigorous demands of both local and national projects. We understand that the integrity of your work hinges on the reliability of every component, which is why we provide fasteners you can trust, backed by generations of expertise right here in the Waikato.
The composition of Grade 8.8 bolts is a careful balance, primarily consisting of medium carbon steel that is quenched and tempered to achieve its notable strength. This specific heat treatment process is key, resulting in a minimum tensile strength of 800 MPa and a yield strength of 640 MPa. This combination means these bolts offer an excellent resistance to stretching and snapping under heavy loads, providing a dependable blend of durability and toughness for a wide array of structural and mechanical applications.
| AStm Standards | DIN ISO EN 4017 & 4014 DIN 933 / 931 & IS 1363 / 1363 |
| Size | Diameter 20 to 100 Milimeter / Inch 3/4 to 3.1/2 |
| Surface Finish | Zinc plated / Plain / Hot dip galvanised |
| CLASS | MATERIAL AND TREATMENT | C | C | P | S | B | TEMPERING TEMP. [C] |
|---|---|---|---|---|---|---|---|
| MIN | MAX | MAX | MAX | MAX | |||
| 8.8 | CARBON STEEL WITH ADDITIVES (E.G. B, MN OR CR) QUENCHED AND TEMPERED | 0.15 (D) | 0.4 | 0.025 | 0.025 | 0.003 | 425 |
| CARBON STEEL QUENCHED AND TEMPERED | 0.25 | 0.55 | 0.035 | 0.025 |
| Grades | Size Range | PS [MPa] | YS (min) [MPa] | TS (min) [MPa] | Hardness [Rockwell] |
|---|---|---|---|---|---|
| Class 8.8 | Under M16 | 580 | 640 | 800 | |
| 17-72 | 600 | 660 | 830 | C23–34 |
| Bolt Dia | Body Dia | Head Dia(F) | Head Height (H) | Degree of Slope | |||
|---|---|---|---|---|---|---|---|
| (D) | Max | Max Edge Sharp | Min Edge Sharp | Absolute Min Rounded | Max | Min | Â |
| 1/2 | 0.515 | 0.935 | 0.905 | 0.845 | 0.269 | 0.233 | 78° to 82° |
| 5/8 | 0.642 | 1.169 | 1.132 | 1.066 | 0.336 | 0.292 | 78° to 82° |
| 3/4 | 0.768 | 1.402 | 1.357 | 1.285 | 0.403 | 0.349 | 78° to 82° |
| 7/8 | 0.895 | 1.637 | 1.584 | 1.511 | 0.47 | 0.408 | 78° to 82° |
| 1 | 1.022 | 1.869 | 1.81 | 1.735 | 0.537 | 0.466 | 78° to 82° |
| 1-1/8 | 1.149 | 2.104 | 2.037 | 1.962 | 0.604 | 0.525 | 78° to 82° |
| 1-1/4 | 1.277 | 2.337 | 2.262 | 2.187 | 0.671 | 0.582 | 78° to 82° |
| 1-3/8 | 1.404 | 2.571 | 2.489 | 2.414 | 0.738 | 0.641 | 78° to 82° |
| 1-1/2 | 1.531 | 2.804 | 2.715 | 2.64 | 0.805 | 0.698 | 78° to 82° |
| Dimensions per ASME B18.5 1990 (R 1998) | |||||||
| Diameter Chart | M4 | M5 | M6 | M8 | M10 | M12 | M14 | M16 | M18 | M20 | M22 | M24 | M27 | M30 | M33 | M36 | M39 | M42 | M45 | M48 | M52 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Pitch List | 0.7 | 0.8 | 1 | 1.25 | 1.5 | 1.75 | 2 | 2.5 | 3 | 3.5 | 4 | 4.5 | 5 | ||||||||
| GR A Length | 40 | 50 | 60 | 80 | 100 | 120 | 140 | 150 | Grade A not applicable to these dia’s | ||||||||||||
Head Across Flat (S) Nom = Max Min GR A GR B | 7 | 8 | 10 | 13 | 16 | 18 | 21 | 24 | 27 | 30 | 34 | 36 | 41 | 46 | 50 | 55 | 60 | 65 | 70 | 75 | 80 |
| 6.78 | 7.78 | 9.78 | 12.73 | 15.73 | 17.73 | 20.67 | 23.67 | 26.67 | 29.67 | 33.38 | 35.38 | GR A not applicable to these diameters | |||||||||
| 6.64 | 7.64 | 9.64 | 12.57 | 15.57 | 17.57 | 20.16 | 23.16 | 26.16 | 29.16 | 33 | 35 | 40 | 45 | 49 | 53.8 | 58.8 | 63.1 | 68.1 | 73.1 | 78.1 | |
Head Height Nom Tol + or – GR A GR B | 2.8 | 3.5 | 4 | 5.3 | 6.4 | 7.5 | 8.8 | 10 | 11.5 | 12.5 | 14 | 15 | 17 | 18.7 | 21 | 22.5 | 25 | 26 | 28 | 30 | 33 |
| 0.125 | 0.15 | 0.18 | 0.215 | GR A not applicable to these diameters | |||||||||||||||||
| 0.2 | 0.24 | 0.29 | 0.35 | 0.42 | 0.5 | ||||||||||||||||
Across corners e Min GR A GR B | 7.66 | 8.79 | 11.05 | 14.38 | 17.77 | 20.03 | 23.36 | 26.75 | 30.14 | 33.53 | 37.72 | 39.98 | GR A not applicable to these diameters | ||||||||
| 7.5 | 8.63 | 10.89 | 14.2 | 17.59 | 19.85 | 22.78 | 26.17 | 29.56 | 32.95 | 37.29 | 39.55 | 45.2 | 50.85 | 55.37 | 60.79 | 66.44 | 71.3 | 76.95 | 82.6 | 88.25 | |
Thread Length (b) For lengths < or = 125ilimeter For lengths > 12ilimeter <= 200milimeter For lengths > 200ilimeter | 14 | 16 | 18 | 22 | 26 | 30 | 34 | 38 | 42 | 46 | 50 | 54 | 60 | 66 | Not specified as full thread recommended | ||||||
| 20 | 22 | 24 | 28 | 32 | 36 | 40 | 44 | 48 | 52 | 56 | 60 | 66 | 72 | 78 | 84 | 90 | 96 | 102 | 108 | 116 | |
| 33 | 35 | 37 | 41 | 45 | 49 | 53 | 57 | 61 | 65 | 69 | 73 | 79 | 85 | 91 | 97 | 103 | 109 | 115 | 121 | 129 | |
| Major Diameter at thread (minimum) | 3.838 | 4.826 | 5.794 | 7.76 | 9.732 | 11.701 | 13.682 | 15.682 | 17.623 | 19.623 | 21.623 | 23.577 | 26.577 | 29.522 | 32.522 | 35.465 | 38.465 | 41.437 | 44.437 | 47.399 | 51.399 |
| Major Dia at thread (maximum) | 3.978 | 4.976 | 5.974 | 7.972 | 9.968 | 11.966 | 13.962 | 15.962 | 17.958 | ||||||||||||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a trusted manufacturer and supplier of high-quality Alloy Steel Gr 8.8 Bolts in Hamilton, New Zealand. We specialize in premium steel products, including Alloy Steel, Carbon Steel, Mild Steel and Galvanized Steel, with a strong focus on Carbon Steel Sheet and Plates. Our extensive inventory also includes Pipes, Tubes, Flanges, Forged Fittings and Bars. Committed to fast delivery and exceptional customer service, we use only the finest raw materials to ensure superior strength, durability and performance for critical industrial applications. Contact us today for all your Alloy Steel Gr 8.8 Bolts needs!
You’ll find Grade 8.8 bolts are the go-to choice for a multitude of uses, from securing the steel frames of new buildings and bridges to assembling heavy machinery and automotive components. Their reliable strength makes them ideal for demanding environments where vibration and significant stress are common. Whether it’s for a major construction project in Auckland, agricultural equipment in the Canterbury plains, or factory machinery down the road in Hamilton, these bolts provide the essential, trusted connection that ensures safety and longevity.
Latham Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Hamilton, New Zealand.
